Materials and Structure
Made from die-casting aluminum housing with PC lens and glass panel.
Light efficacy: 130-190 lm/W, selectable beam angles: 60°, 90°, 120°, T2M, or T3M.
IP65 protection rating.
LED chip options: 3030, 5050, or 7070; driver options: Inventronics, MeanWell, Philips, or MOSO brands.
Operating temperature: -40°C to 50°C, lifespan 50,000 hours.
Surface Treatment
Electrostatic powder coating, colors customizable as required.
Size Specifications
Power: 40W, 75W, 100W, 150W, 200W, 300W.
Voltage: AC100-277V, PF > 0.95, color temperature 3000-6500K.
Installation Configuration
Side mount or top mount, compatible with standard light poles.
Optional 0-10V dimming.
Application Scenarios
Urban main road and expressway lighting, highway and toll station lighting, port and container terminal lighting, airport apron and cargo area lighting, large industrial park and logistics park lighting.
| Model | THSL10-40W | THSL10-75W | THSL10-100W | THSL10-150W | THSL10-200W | THSL10-300W |
| Power | 40W | 75W | 100W | 150W | 200W | 300W |
| Voltage | AC 100-277V | |||||
| Frequency Range | 50-60HZ | |||||
| PF | >0.95 | |||||
| CCT | 3000K-6500K | |||||
| Lamp Brand | 3030/5050/7070 | |||||
| IP Rating | IP65 | |||||
| Beam Angle | 60°/90°/120°/T2M/T3M | |||||
| LED Driver | Inventronics/MeanWell/Philips/MOSO | |||||
| Raw Material | Die-cast Aluminum+PC Lens+Glass | |||||
| Luminous Efficiency | 130-190LM/ W | |||||
| Working Temperature | -40°C~50°C | |||||
| Life | 50000H | |||||
